GitHub – unhaya/vam-seek: 2D Video Seek Marker

A lightweight 2D video seek grid library for video streaming sites.

Navigate videos visually with a thumbnail grid instead of a 1D seek bar. Client-side frame extraction with smooth marker animation.

🎯 Stop blind scrubbing. See every scene at once.

Keywords: video player, video seek, thumbnail grid, video navigation, HTML5 video, JavaScript library, video streaming, media player, video controls, video thumbnails, seek bar alternative, video UX

<!-- 1. Add the script -->
<script src="https://cdn.jsdelivr.net/gh/unhaya/vam-seek/dist/vam-seek.js"></script>

<!-- 2. Connect to your video -->
<script>
  VAMSeek.init({
    video: document.getElementById('myVideo'),
    container: document.getElementById('seekGrid'),
    columns: 5,
    secondsPerCell: 15
  });
</script>

That’s it. See docs/INTEGRATION.md for full documentation.

• Client-side frame extraction – No server CPU usage
• LRU cache – 200 frames cached in memory
• Smooth marker animation – 60fps with requestAnimationFrame
• VAM algorithm – Precise timestamp calculation
• Framework support – React, Vue, vanilla JS examples included

Your video never leaves the browser.

Traditional thumbnail systems upload videos to a server, process with FFmpeg, store thumbnails, and serve via CDN. This costs money, takes time, and raises privacy concerns.

VAM Seek works differently:

All frame extraction happens in the user’s browser using the Canvas API. When the page closes, everything is gone. No data is ever sent to any server.

VAM_web/
├── dist/                       # Distributable files
│   └── vam-seek.js             # Standalone library (1 file, ~15KB)
│
├── docs/                       # Documentation
│   └── INTEGRATION.md          # API integration guide
│
├── examples/                   # Integration examples
│   ├── basic-integration.html  # Vanilla JS example
│   ├── react-integration.jsx   # React component & hook
│   └── vue-integration.vue     # Vue 3 component
│
├── backend/                    # FastAPI backend (for demo)
│   ├── main.py                 # Entry point, static file serving
│   ├── requirements.txt        # Python dependencies
│   ├── core/                   # Core logic
│   │   ├── grid_calc.py        # VAM grid calculation
│   │   └── video_utils.py      # FFmpeg video processing
│   ├── models/                 # Pydantic schemas
│   │   └── schemas.py          # Request/response models
│   ├── routers/                # API routers
│   │   ├── grid.py             # /api/grid/* endpoints
│   │   └── video.py            # /api/video/* endpoints
│   ├── uploads/                # Uploaded videos (gitignore)
│   └── thumbnails/             # Generated thumbnails (gitignore)
│
├── frontend/                   # Demo frontend
│   ├── index.html              # Main UI with embedded JS
│   └── assets/
│       └── marker.svg          # Grid marker icon
│
├── .gitignore
└── README.md

CDN (Recommended)

<script src="https://cdn.jsdelivr.net/gh/unhaya/vam-seek/dist/vam-seek.js"></script>

npm

const vam = VAMSeek.init({
  video: document.getElementById('video'),
  container: document.getElementById('grid'),
  columns: 5,
  secondsPerCell: 15,
  onSeek: (time, cell) => {
    console.log(`Seeked to ${time}s`);
  }
});

// API
vam.seekTo(120);           // Seek to 2:00
vam.moveToCell(2, 3);      // Move to column 2, row 3
vam.configure({ columns: 8 }); // Update settings
vam.destroy();             // Clean up

• Python 3.9+
• FFmpeg (in PATH)

cd backend
pip install -r requirements.txt
python main.py

Open http://localhost:8000

// 1. Create hidden video element
const video = document.createElement('video');
video.src = "https://github.com/unhaya/video.mp4";

// 2. Seek to timestamp
video.currentTime = 15.0;

// 3. Capture on seeked event
video.addEventListener('seeked', () => {
  const canvas = document.createElement('canvas');
  ctx.drawImage(video, 0, 0);
  const dataUrl = canvas.toDataURL('image/jpeg', 0.8);
});

// 4. Cache with LRU (max 200 frames)
frameCache.put(videoSrc, timestamp, dataUrl);

// X-continuous timestamp calculation
function calculateTimestamp(x, y, gridWidth, gridHeight, duration, secondsPerCell) {
  const rowIndex = Math.floor(y / gridHeight * rows);
  const colContinuous = x / gridWidth * columns;
  const cellIndex = rowIndex * columns + colContinuous;
  return Math.min(cellIndex * secondsPerCell, duration);
}

• Chrome 80+
• Firefox 75+
• Safari 14+
• Edge 80+
• Mobile browsers

Free for personal, educational, and research use.
Commercial use requires a paid license. Contact: info@haasiy.jp

• FastAPI backend with modular architecture
• Client-side frame extraction (video + canvas)
• VAM-compliant marker movement (X-continuous mode)
• LRU cache with fade-in animation
• Scroll position fix
• Same-origin serving for CORS

• Standalone vam-seek.js for external integration
• Integration documentation
• React, Vue examples

Based on VAM Desktop application algorithms:

• vam5.70/utils/video_utils.py – calculate_x_continuous_timestamp
• vam5.70/gui/preview/core/grid_calculator.py – GridCalculator
